SC 600 HDTR
Besilen® izolasyonlu tel, Besilen® dış kılıflı
Marking for SC 600 HDTR 01270410: SAB BRÖCKSKES · D-VIERSEN · SC 600 HDTR UL AWM Style 4511 200°C 60OV cUL AWM I/II A/B 200°C 600V FT1 FT2 CE
Kullaniş
SC 600 HDTR has a Besilen® 722 insulation and consists of insulated strands with silicone outer sheath. It finds its application in plastics processing, packaging machine construction, smelteries, steelworks, and hot-rolling mills, safety technology, measuring and control technologies, cement, glass, and ceramic industries, refrigeration, heat and air conditioning technologies, power plants, and sauna construction.
Özel özellikler
- halogen-free
- flexible at low temperatures
- heat resistant
Yapı
| Conductor | tinned copper strands acc. to IEC 60228, EN 60228, VDE 0295, class 5 |
|---|---|
| Insulation | Besilen® |
| Colour code | up to 5 cores coloured acc. to HD 308 (VDE 0293 part 308); from 6 cores black cores with consecutive numbers acc. to EN 50334; from 3 cores a green-yellow earth wire |
| Stranding | in layers |
| Sheath material | Besilen ® better than EM9 acc. to DIN EN 50363-2-1 |
| Sheath colour | reddish brown (similar RAL 3016) |
tinned copper strands acc. to IEC 60228, EN 60228, VDE 0295, class 5
Besilen®
up to 5 cores coloured acc. to HD 308 (VDE 0293 part 308); from 6 cores black cores with consecutive numbers acc. to EN 50334; from 3 cores a green-yellow earth wire
in layers
Besilen ® better than EM9 acc. to DIN EN 50363-2-1
reddish brown (similar RAL 3016)
Teknik veriler
| Voltage | UL + cUL: 600V |
|---|---|
| Nominal voltage | DIN VDE: Uo/U 300/500 V |
| Testing voltage | 2000 V acc. to DIN VDE 0281 part 2 + HD 21.2 |
| Min. bending radius | fixed laying: 4 x d flexible application: 6 x d |
| Radiation resistance | 2 x 10^7 cJ/kg |
| Temperature range | UL: up to +200°C cUL: up to +200°C
DIN VDE: fixed laying: -40/+180°C flexible application: -25/+180°C short-time use: +250°C |
| Halogen-free | acc. to DIN VDE 0472 part 815 and IEC 60754-1 |
| Fire performance | flame retardant and self-extinguishing acc. to IEC 60332-1-2 and EN 60332-1-2, cUL FT1 and FT2 |
| Corrosiveness of conflagration gases | IEC 60754-2 + EN 50267-2-2 + VDE 0482 part 267-2-2 - no development of corrosive conflagration gases |
| Absence of harmful substances | acc. to RoHS directive of the European Union |
UL + cUL: 600V
DIN VDE: Uo/U 300/500 V
2000 V acc. to DIN VDE 0281 part 2 + HD 21.2
fixed laying: 4 x d
flexible application: 6 x d
2 x 10^7 cJ/kg
UL: up to +200°C
cUL: up to +200°C
DIN VDE:
fixed laying: -40/+180°C
flexible application: -25/+180°C
short-time use: +250°C
acc. to DIN VDE 0472 part 815 and IEC 60754-1
flame retardant and self-extinguishing acc. to IEC 60332-1-2 and EN 60332-1-2, cUL FT1 and FT2
IEC 60754-2 + EN 50267-2-2 + VDE 0482 part 267-2-2 - no development of corrosive conflagration gases
acc. to RoHS directive of the European Union
